PiGi (Radiation Messurement)

Hello and Moin Moin from the north of Germany! :slight_smile:

Sorry for my english. :-/

I wanna tell you the PCB for the PiGi is now to order at PCBs.io.

At https://pcbs.io/share/r1Dq6 you can order the PCB.

The missing Parts (electronic) you can order at Mouser. It was an Projektorder to get what you need for the PiGi.
Link: https://mouser.com/ProjectManager/ProjectDetail.aspx?AccessID=48c6646594

The Geiger-Müller-Tube you can order at ebay. Look at SMB-20. Kostst roundabout 25€.

For more information look at :
https://apollo.open-resource.org/mission:log:2017:07:17:pigi-pcbs-now-available-on-pcbs.io

And the Mainsite: https://apollo.open-resource.org/lab:pigi

Greets

Nordrunner

P.S.: I hope i read you at our Channel at: https://matrix.to/#/#iotde:matrix.ffslfl.net (Webclient)

1 Like

Ups…

At our WIKI some more information (german): http://wiki.iot-usergroup.de/index.php/PiGi

Nordrunner

How we can get this ready for our IoT (LoRa and TTN)?

I ask myself… how do you test such a device ?

Hello! :smile:

Good question @BoRRoZ !

Most answers find here: https://apollo.open-resource.org/lab:pigi:hardware

The home of the PiGi-Projekt.

For a comparison I have to adjust before the official value of a measuring point here on site.
http://odlinfo.bfs.de/DE/aktuelles/messstelle/010591161.html

Oh, @Caspar has a purchase at Mouser. However, delivery times from > 2018 are given.

So if someone knows a way, where you can create a similar project-related order list …?

chrono reported the CEO of Makerbright has reported and would like to offer the PiGi as a complete package. Let’s see what happens.

greetings

Nordrunner

Test sources are a lot more common than you might think. We are swimming through a sea of background radiation on a daily basis. Most of it has nothing to do with the apocalypse and is quite normal.

Common test sources (other than dismantling smoke detectors which is illegal in some places):-

Uranium Glass (can be found in junk shops if you have a UV torch).
LoSalt or anything containing a lot of potasium (K40).
Atmospheric Radon (commonly occurring in places with uranium deposits).
Radium commonly found on old glow in the dark watch hands and faces.

A fun way to collect together enough atmospheric Radon for a simple experiment is written up at:-

2 Likes

As the Minions would say….BANANAS! :wink: (Good source of potassium…)

1 Like

Not quite in the right bit of the graph I was thinking of when i wrote “a lot of potassium” but very eye catching.

XKCD’s poster puts it all in a more understandable perspective, and has Bananas on it.

https://xkcd.com/radiation/

1 Like

Would you believe my son just doing end of 2nd yr for 4 yr MSc Phy and for labs last term they were asked to bring in Banana as an ‘every day’ source they could measure/evaluate in rad lab which is why it was in mind :slight_smile: …love the chart - have passed link on to him! :wink:

Bannanas are one of those meme’s that has somehow gripped the public’s imagination. But are not really a particularly good measure. The BED (Bannana Equivalent Dose) is incredibly variable.

Other foodstuffs are more radioactive. LoSalt being one. Brasil Nuts are another.

Some plants sequester away heavy elements to safeguard the rest of them. Brasils do this and you can get buildup of heavier elements in the nuts if it is present in the environment they were grown in. A decent Gamma spectrometry rig will let you see what these are by their unique gamma lines. It is fun to play wiht this sort of kit and try random sample bought in local supermarkets and stores, to see what is in it.

If the gamma spec kit is sensitive enough you have to take a background spectrum and subtract it so as to see the weaker traces.

Certain areas of the UK are quite radiologicaly lively due to local geological deposits, more so when industrial activity has dumped it all over the surface.

A project that monitors this natural-ish background and reports on it is not actually a bad idea.

https://www.ebay.com/sch/hentell001/m.html?_nkw=&_armrs=1&_ipg=&_from=

I personally tested “URANIUM Czech glass Vaseline yellow round beads 6 mm 50 pcs”

You can verify it actually is uranium oxide glass by shining some UV on it : it gets fluorescent.

For storage if you are paranoid you can use a few of those : https://www.ebay.com/itm/NEW-Lead-Pig-Container-for-radioactive-Materials/202163948485
