RAK811 breakout pinout

End Devices (Nodes) Hardware
21

I want to use the breaboad to test my gateways coverage thats the main idea

22

Still unable to communicate with wisnode with plugged into arduino uno

23

I suggest the RAK forum :wink:

24

did anyone already try to connect the wisnode lora -rak 811- board version 1.2 to a raspberry pi 3 yet?
I am not sure about the wiring because.

25

Did someone use the i2c? Im trying to use it with a BME280 sensor but i cant,
I tried with AT command (at+rd_iic=0x76,0x60,0x24) and C Code:

I2cResetBus( &i2c );
ret = I2cReadBuffer( &i2c, 0x60, BME280_I2C_ADDR_PRIM, dev_buf, 24 );

Also i couldnt find some information about it in Internet.

26

Hi, I am using atttiny85 with 3 PIR sensors, but there is only one external interrupt, is there any way I can use attachinterrupt (Iā€™m using arduino IDE) with all 3 sensor pins. I have tested it with 1 sensor only, where I was usig PB2 as my sensor pin. PB2 is attached to INT0.
Ps. Iā€™m a beginnerā€¦

27

If you are using an ATtiny85 with three sensor pins, that doesnā€™t leave much for a LoRa radio so you can have a LoRaWAN device, leaving aside the status of TinyLoRa.

If you arenā€™t using LoRaWAN, the Arduino forum is much better suited to answering Arduino questions.
